Input Voltage:100-240V 50/60 Hz

Light Source: Osram 461W/ 21R Lamp

Gobos：one static gobo wheel: 14 gobos+ open

Color：one color wheel 14 colors+ open

Prism: Prism wheel 1: 6 facet prism ， 16 facet prism,

Prism wheel 2: 32 facet prism + 6 facet linear prism

+ (6+12 facet) combined prism

Beam angle： 1.8°

Dimming：0～100% Linear dimming

Strobe：With strobe effect

Frost：With frost effect

Display:LCD display

Channel： 16/19 CH

Control Mode：DMX 512,RDM,Artnet(optional),Auto-running ,

Master/salve, Sound active, Built-in program

Movement：Pan 540°；Tilt 270°；

Auto X/Y repositioning, fast, quiet and smooth

Gross weight: 23KG

Net Weight：21KG

Packing size: 480*460*735MM
