6 DMX outputs, 1 DMX input, expander connected, support up to 65536 channel parameters

Built-in 3 electric adjustable wide viewing angle 15.4 inch touch screen + 1 9 inch high brightness multi-touch screen,

2 external touch screens, 30 high-precision electric actuators (60mm)

2 AB field electric actuators (100mm)

1 main control electric actuator

7 German optical encoders (with PUSH function)

1 highly sensitive trackball

2 Gigabit Ethernet ports, support MA NET, ARTNET, ETC NET2,

PATHPORT, SCAN, SHOWNET, KINET1 SIGNALS, 5 USB2.0 PORTS

Individually adjustable yellow backlit keys with built-in keyboard and drawer

MIDI input and output interface, LTC/SMPTE timecode

Built-in 60G SSD, I5 CPU, 8G memory

Compatible with MA1 and MA2 systems, any version can be upgraded at will

Supports multiple online backups

Supports handheld remote control

Support stage 3D effect simulation, real-time live simulation

AC wide voltage power supply: 100-240 V, 50/60Hz, built-in uninterruptible power supply (UPS)

Console size: 130cm*66cm*21cm, flight box size: 134CM*87CM*33CM

Net weight: 55KG Gross weight: 100KG
